Deckline
Deckline ropes are a special economy line that combines the abrasion resistance and tenacity of our Movline Plus bi-polymer fiber. This cost effective floating rope has good wear and abrasion resistance given by the outer Movline cover and higher breaking resistance when compared to other traditional PP ropes.
-
- Cost effective compared to traditional PP ropes
- High abrasion resistance
- Good breaking strength
- Excellent UV resistance
-
-
- Raw material: Mixed Polyolefin
- Specific Gravity: 0,93
- Melting Point: 165ºC
- Elongation at % of BS:
25% …. 6,0%
50% …. 11,5%
Diameter Size
Circ.Weight Breaking Load mm Inches Inches Ktex Kg/100m lbs/100ft Kgf lbf kN 24 1 3 261 26,1 17,5 8 056 17 760 79 26 1 1/32 3 1/4 306 30,6 20,6 9 279 20 457 91 28 1 1/8 3 1/2 355 35,5 23,9 10 707 23 605 105 30 1 1/4 3 3/4 408 40,8 27,4 12 135 26 752 119 32 1 5/16 4 464 46,4 31,2 13 664 30 124 134 34 1 11/32 4 1/4 525 52,5 35,3 15 194 33 496 149 36 1 1/2 4 1/2 587 58,7 39,4 16 825 37 093 165 38 1 9/16 4 3/4 656 65,6 44,1 18 559 40 915 182 40 1 5/8 5 725 72,5 48,7 20 292 44 736 199 44 1 3/4 5 1/2 877 87,7 58,9 23 963 52 829 235 48 2 6 1 040 104 69,9 28 144 62 046 276 52 2 1/8 6 1/2 1 220 122 82 32 631 71 938 320 56 2 1/4 7 1 420 142 95,4 37 220 82 054 365 60 2 1/2 7 1/2 1 630 163 109,5 42 114 92 845 413 64 2 5/8 8 1 860 186 125 47 111 103 860 462 68 2 3/4 8 1/2 2 100 210 141,1 52 821 116 450 518 72 2 7/8 9 2 350 235 157,9 58 634 129 263 575 80 3 1/4 10 2 900 290 194,9 70 871 156 240 695 90 3 9/16 11 1/8 3 750 375 252 91 673 202 101 899
Above breaking loads are for 3 strand ropes. On 4 strand ropes, breaking loads are approximately 10% lower.
- General deck lines
- Tie-up lines
-
- Raw material: Mixed Polyolefin
- Specific Gravity: 0,93
- Melting Point: 165ºC
- Elongation at % of BS:
25% …. 6,0%
50% …. 11,5%
| Diameter | Size Circ. | Weight | Breaking Load | |||||
| mm | Inches | Inches | Ktex | Kg/100m | lbs/100ft | Kgf | lbf | kN |
| 24 | 1 | 3 | 261 | 26,1 | 17,5 | 8 056 | 17 760 | 79 |
| 26 | 1 1/32 | 3 1/4 | 306 | 30,6 | 20,6 | 9 279 | 20 457 | 91 |
| 28 | 1 1/8 | 3 1/2 | 355 | 35,5 | 23,9 | 10 707 | 23 605 | 105 |
| 30 | 1 1/4 | 3 3/4 | 408 | 40,8 | 27,4 | 12 135 | 26 752 | 119 |
| 32 | 1 5/16 | 4 | 464 | 46,4 | 31,2 | 13 664 | 30 124 | 134 |
| 34 | 1 11/32 | 4 1/4 | 525 | 52,5 | 35,3 | 15 194 | 33 496 | 149 |
| 36 | 1 1/2 | 4 1/2 | 587 | 58,7 | 39,4 | 16 825 | 37 093 | 165 |
| 38 | 1 9/16 | 4 3/4 | 656 | 65,6 | 44,1 | 18 559 | 40 915 | 182 |
| 40 | 1 5/8 | 5 | 725 | 72,5 | 48,7 | 20 292 | 44 736 | 199 |
| 44 | 1 3/4 | 5 1/2 | 877 | 87,7 | 58,9 | 23 963 | 52 829 | 235 |
| 48 | 2 | 6 | 1 040 | 104 | 69,9 | 28 144 | 62 046 | 276 |
| 52 | 2 1/8 | 6 1/2 | 1 220 | 122 | 82 | 32 631 | 71 938 | 320 |
| 56 | 2 1/4 | 7 | 1 420 | 142 | 95,4 | 37 220 | 82 054 | 365 |
| 60 | 2 1/2 | 7 1/2 | 1 630 | 163 | 109,5 | 42 114 | 92 845 | 413 |
| 64 | 2 5/8 | 8 | 1 860 | 186 | 125 | 47 111 | 103 860 | 462 |
| 68 | 2 3/4 | 8 1/2 | 2 100 | 210 | 141,1 | 52 821 | 116 450 | 518 |
| 72 | 2 7/8 | 9 | 2 350 | 235 | 157,9 | 58 634 | 129 263 | 575 |
| 80 | 3 1/4 | 10 | 2 900 | 290 | 194,9 | 70 871 | 156 240 | 695 |
| 90 | 3 9/16 | 11 1/8 | 3 750 | 375 | 252 | 91 673 | 202 101 | 899 |
Above breaking loads are for 3 strand ropes. On 4 strand ropes, breaking loads are approximately 10% lower.
