PA Braided
-
- Braided construction;
- Good abrasion resistance;
- Excellent breaking load;
- High elasticity;
- Thermo-stabilized for dimensional uniformity and stability of the meshes;
- Possibility of a special coating upon request.
-
Ref.ª Appox. Diam. Runnage Knot Resistance # mm m/kg tol. kgf tol. 8842 1,8 581 ± 5% 95 ± 10% 8843 2 430 170 4840/3 2,5 280 250 4840/4 3,2 190 330 4840/5 4,1 105 510 4840/6 4,4 90 545 4840/7 5,1 70 580 4840/8 5,8 50 820 4840/9 7,2 35 1 025
The above figures are for guidance purposes only, Cotesi cannot be held liable for deviations.
We reserve the right to change them without prior notice.
| Ref.ª | Appox. Diam. | Runnage | Knot Resistance | ||
| # | mm | m/kg | tol. | kgf | tol. |
| 8842 | 1,8 | 581 | ± 5% | 95 | ± 10% |
| 8843 | 2 | 430 | 170 | ||
| 4840/3 | 2,5 | 280 | 250 | ||
| 4840/4 | 3,2 | 190 | 330 | ||
| 4840/5 | 4,1 | 105 | 510 | ||
| 4840/6 | 4,4 | 90 | 545 | ||
| 4840/7 | 5,1 | 70 | 580 | ||
| 4840/8 | 5,8 | 50 | 820 | ||
| 4840/9 | 7,2 | 35 | 1 025 | ||
The above figures are for guidance purposes only, Cotesi cannot be held liable for deviations.
We reserve the right to change them without prior notice.
