Combo
A blended rope that combines the best properties of Polyester fiber with our Movline bi-polymer fiber in a unique twisted balanced construction where every single Movline yarn is covered with Polyester, giving it an exceptional wearing resistance and strength with significantly less handling weight than an all polyester ropes.
-
- Exceptional abrasion and wear resistance
- 18-20% lighter than an all polyester constructions
- Less water absorption than an all polyester ropes
- Smooth balanced construction
-
-
- Raw material: Mixed Polyolefin / Polyester
- Specific Gravity: 1,16
- Melting Point: 165ºC / 265ºC
- Elongation at % of BS:
25% …. 4,0%
50% …. 7,0%
Diameter Size
Circ.Weight Breaking Load mm Inches Inches Ktex Kg/100m lbs/100ft Kgf lbf kN 24 1 3 279 27,9 18,7 9 820 21 649 96,3 26 1 1/32 3 1/4 328 32,8 22 11 523 25 403 113 28 1 1/8 3 1/2 380 38 25,5 13 256 29 225 130 30 1 1/4 3 3/4 437 43,7 29,4 15 092 33 271 148 32 1 5/16 4 497 49,7 33,4 17 029 37 543 167 34 1 11/32 4 1/4 563 56,3 37,8 19 273 42 488 189 36 1 1/2 4 1/2 629 62,9 42,3 21 414 47 209 210 38 1 9/16 4 3/4 703 70,3 47,2 23 861 52 605 234 40 1 5/8 5 776 77,6 52,1 26 207 57 775 257 44 1 3/4 5 1/2 939 93,9 63,1 31 407 69 240 308 48 2 6 1 110 111 74,6 37 118 81 829 364 52 2 1/8 6 1/2 1 320 132 88,7 43 236 95 318 424 56 2 1/4 7 1 520 152 102,1 49 864 109 930 489 60 2 1/2 7 1/2 1 750 175 117,6 56 900 125 442 558 64 2 5/8 8 1 990 199 133,7 64 344 141 853 631 68 2 3/4 8 1/2 2 250 225 151,2 72 094 158 938 707 72 2 7/8 9 2 520 252 169,3 80 456 177 372 789 80 3 1/4 10 3 110 311 209 98 199 216 488 963 90 3 9/16 11 1/8 3 930 393 264,1 123 692 272 690 1 213 In accordance to ISO 14686-2004
Above breaking loads are for 3 strand ropes. On 4 strand ropes, breaking loads are approximately 10% lower.
- Barge working lines
- Tie-up lines
- General deck lines
-
- Raw material: Mixed Polyolefin / Polyester
- Specific Gravity: 1,16
- Melting Point: 165ºC / 265ºC
- Elongation at % of BS:
25% …. 4,0%
50% …. 7,0%
| Diameter | Size Circ. | Weight | Breaking Load | |||||
| mm | Inches | Inches | Ktex | Kg/100m | lbs/100ft | Kgf | lbf | kN |
| 24 | 1 | 3 | 279 | 27,9 | 18,7 | 9 820 | 21 649 | 96,3 |
| 26 | 1 1/32 | 3 1/4 | 328 | 32,8 | 22 | 11 523 | 25 403 | 113 |
| 28 | 1 1/8 | 3 1/2 | 380 | 38 | 25,5 | 13 256 | 29 225 | 130 |
| 30 | 1 1/4 | 3 3/4 | 437 | 43,7 | 29,4 | 15 092 | 33 271 | 148 |
| 32 | 1 5/16 | 4 | 497 | 49,7 | 33,4 | 17 029 | 37 543 | 167 |
| 34 | 1 11/32 | 4 1/4 | 563 | 56,3 | 37,8 | 19 273 | 42 488 | 189 |
| 36 | 1 1/2 | 4 1/2 | 629 | 62,9 | 42,3 | 21 414 | 47 209 | 210 |
| 38 | 1 9/16 | 4 3/4 | 703 | 70,3 | 47,2 | 23 861 | 52 605 | 234 |
| 40 | 1 5/8 | 5 | 776 | 77,6 | 52,1 | 26 207 | 57 775 | 257 |
| 44 | 1 3/4 | 5 1/2 | 939 | 93,9 | 63,1 | 31 407 | 69 240 | 308 |
| 48 | 2 | 6 | 1 110 | 111 | 74,6 | 37 118 | 81 829 | 364 |
| 52 | 2 1/8 | 6 1/2 | 1 320 | 132 | 88,7 | 43 236 | 95 318 | 424 |
| 56 | 2 1/4 | 7 | 1 520 | 152 | 102,1 | 49 864 | 109 930 | 489 |
| 60 | 2 1/2 | 7 1/2 | 1 750 | 175 | 117,6 | 56 900 | 125 442 | 558 |
| 64 | 2 5/8 | 8 | 1 990 | 199 | 133,7 | 64 344 | 141 853 | 631 |
| 68 | 2 3/4 | 8 1/2 | 2 250 | 225 | 151,2 | 72 094 | 158 938 | 707 |
| 72 | 2 7/8 | 9 | 2 520 | 252 | 169,3 | 80 456 | 177 372 | 789 |
| 80 | 3 1/4 | 10 | 3 110 | 311 | 209 | 98 199 | 216 488 | 963 |
| 90 | 3 9/16 | 11 1/8 | 3 930 | 393 | 264,1 | 123 692 | 272 690 | 1 213 |
In accordance to ISO 14686-2004
Above breaking loads are for 3 strand ropes. On 4 strand ropes, breaking loads are approximately 10% lower.
