Berthing Rope

Berthing Rope

A 12 strands round plait line that combines the high tenacity, abrasion and wear resistance of polyester with Spun PP. This very special blend along with its unique construction that perfectly combines these two fibers, gives this rope a superb handling and touch, highly appreciated by national marine defence fleets.
  • Advantages
    • Superb handling and touch
    • Good abrasion and wear resistance
    • Low water absorption
    • Flexible, non kinking and non rotating
  • Applications
    • Mooring lines
    • Anchor lines
  • Tecnhical Informations
    • Raw material: Spun Polypropylene / Polyester
    • Specific Gravity: 1,16
    • Melting Point: 165C / 265C
    • Elongation at % of BS:
    25% . 3,5%
    50% . 7,9%

    DiameterSize
    Circ.
    WeightBreaking Load
    mminchesinchesktexKg/100mlbs/100ftkgflbfkN
    241340540,527,28.77019.33386,0
    261 1/323 1/443943,929,59.48320.90793,0
    281 1/83 1/247347,331,810.19722.481100,0
    301 1/43 3/454354,336,510.80923.829106,0
    321 5/16461461,441,312.23726.977120,0
    361 1/24 1/276076,051,115.09233.271148,0
    401 5/8595095,063,818.86541.589185,0
    441 3/45 1/21175117,579,022.63849.907222,0
    48261364136,491,726.00357.326255,0
    522 1/86 1/21600160,0107,530.08266.318295,0
    562 1/471850185,0124,334.46775.984338,0
    602 1/27 1/22120212,0142,539.15786.326384,0
    642 5/882420242,0162,644.15497.341433,0
    682 3/48 1/22732273,2183,649.456109.031485,0

    The technicals characteristics stated are the result of a Cotesi development and are stricly indicative.
    We reserve the right to change them without prior notice.
    Breaking load values stated shall be reduced by 10 % in the case of a rope with eye-spliced terminations.
